PreSonus StudioLive 32R Series III Digital Rack Mixer

Overview

The PreSonus StudioLive 32R Series III Digital Rack Mixer is both a versatile AVB stage box for StudioLive Series III consoles and the most powerful rack mixer in its class. It can operate as a simple stage box or as a combined stage box/monitor mixer, including remote control of the preamps and phantom power from the Series III console. As with Series III consoles, its fully recallable and features a plug-in-style signal-processing workflow with vintage-style EQ and compression options on every channel; 16 FlexMixes that can be Aux, Subgroup, or Matrix mixes; 4 fixed subgroups; 6-band fully parametric EQ on all mix outputs; and built-in AVB networking. In addition to 40x40 USB and 55x55 AVB recording interfaces, the StudioLive 32R features an onboard stereo SD recorder.

Features:

- 32-channel AVB stage box for StudioLive Series III consoles
- Simple stage box mode
- Stage box + monitor mixer mode with control of preamps and phantom power from StudioLive Series III console
- Fully recallable, 32-channel, Series III digital rack mixer
- 34 total inputs
- 32 locking combo mic/line channel inputs with recallable XMAX Class A mic preamps
- 2 RCA line-level channel inputs (Ch. 31-32)
- 16 1/4" TRS FlexMix outputs
- 2 XLR main outputs (left/right)
- Scene management with Scene Safe
- 16 FlexMixes (Aux mixes, Subgroups, or Matrix mixes)
- 4 dedicated subgroups
- 4 internal effects buses (combination of reverbs and delays with modern and vintage options)
- Fat Channel processing with vintage EQ and Compressor modes available on every channel and A/B compare
- 40x40 USB 2.0 recording interface and 55x55 AVB recording interface
- Onboard stereo recording to SD card

Includes Complete Fat Channel Volume 1 Plug-in Collection!

Complete Fat Channel Volume 1 is a collection of 11 high-end/vintage EQ and compressor plug-ins that can be added to any current StudioLive console or rack mixer to expand its processing power. Fat Channel plug-ins are virtual signal processors that load in your StudioLive mixer's Fat Channel, expanding your Fat Channel processor library much like plug-ins do in a DAW. All are state-modeled to accurately produce the sound and response of the original hardware processors and add new dimensions and texture to your mixes.FC-670 Compressor: This model of an iconic compressor/limiter of the 1950s imparts an unmistakable silky warmth on just about any signal. Brit Comp: Capturing the unique sound of a twin VCA gain-reduction amplifier design, the Brit Comp is ideal for taming piano dynamics or adding punch to drums and percussion.Alpine EQ-550: The 1960s-vintage EQ provides consistent, repeatable equalization using three overlapping bands, divided into seven fixed frequency points, each with five steps of boost or cut. Its selectable peaking or shelving filters for the high and low band, along with an independently insertable bandpass filter, provide an easy path to creating acoustically superior equalization. Solar 69 EQ: The sound of classic British EQ is absolutely legendary and has enhanced many a great recording. Emulating this classic British design, the Solar 69 EQ adds definition to kick drums, shapes electric guitars, and adds shimmer to acoustic guitars and vocals without sacrificing body.Baxandall EQ: This EQ offers the world's most popular EQ curve. Using gently sweeping treble and bass EQ shelves, it allows you to make subtle, yet effective, changes over wide swaths of the frequency spectrum. Comp 160 Compressor: With simple controls, yet capable of extreme compression traits, the Comp 160 provides VCA character with a personality all its own. Try it on drums -
- you’ll be glad you did! Everest C100A Compressor: Expand the processing capabilities of any PreSonus StudioLive Series III console or Series III rack mixer, as well as Studio One, with the Everest C100A Compressor. Based on a classic design focused on gentle, natural-sounding gain reduction, the Everest C100A helps control dynamics while still letting the signal breathe. Classic Compressor: The smooth character of this compressor allows you to create transparent or extreme color changes to your audio, making it a workhorse for just about any application. Vintage 3-band EQ: With its distinct filter shaping, sheen, and bite, this three-band active EQ includes both high and low shelving filters, providing enhanced tone-shaping possibilities. Tube P1B Compressor: Typically, the response time of optical compressors tends to soften the attack and release, which can smooth out uneven volume fluctuations. Emulating an all-tube, optical design, the Tube P1B compressor delivers musicality, preserving the clarity of the signal even at the most extreme settings. Tube Midrange EQ: This midrange EQ is based on a passive, all-tube design for ultra-smooth and musical equalization, making it ideal for any midrange source material.
