Description
Specifications
- Nominal diameter: 12" (305mm)- Power rating: 90W
- Nominal impedance: 8 Ohm
- Sensitivity: 100dB
- Chassis type: Pressed steel
- Voice coil diameter: 1.75" (44.5mm)
- Voice coil material: Round copper
- Magnet type: Alnico
- Frequency range: 75-5000Hz
- Resonance frequency, Fs: 75Hz
- DC resistance, Re: 6.7Ohm
- Cut-out diameter: 11.1" (283mm)
- Diameter: 12.2" (309mm)
- Magnet structure diameter: 5.0" (128mm)
- Mounting slot dimensions: 0.31" (7.9mm) O
- Mounting slot PCD: 11.7" (297mm)
- Number of mounting slots: 8
- Overall depth: 6.5" (165mm)
- Weight: 9.3lb (4.2kg)
